0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M

Author:admin    Pub date:2021-12-25 20:40:10     Views:


0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M
  • 0.2-1.6mm mechanical releasing NC servo roll feeders, model NCF-200M, NCF-300M, NCF-400M

I. Main features
1. These NCF-M series NC servo roll feeders are very excellent feeding machines for thin metal sheet coils, with high quality design and feeding performance.
2. They can suit for various metal sheet coil material, such as cold rolled steel, hot rolled steel, galvanized steel etc.
3. With precise concentric steel rollers, strong mechanical structure, advanced servo motor and servo drive, advanced control system, and other precise components, so each feeder can ensure high quality feeding performance easily.
4. With certificated electric parts, satisfied metal treatment, and safe electrical control, so it can protect users very well.
5. It has a mechanical polit releasing for a roller, with faster speed than pneumatic cylinder polit releasing, so is very suitable for high speed stamping with short feeding length.
6. It has manual operation mode and automatic operation mode. The manual model is for trial feeding operation and feeding performance inspection, also for metal sheet coil end feeding. After inspect successfully, user can turn to automatic mode for continuous mass production easily.
7. It provides three segments of feeding at least, with different feeding length. for each segment. User can input and get various feeding strokes at a touch screen panel
easily.
8. A piece of robber coated roller can be used for feeding thin metal sheet or protecting metal sheet surface well if required.
9. A piece of independent welded supporting bracket can be provided as optional device, to support and mount the feeder frame well.
10. More feeding segments can be equipped as optional device also.
11. Beside English, Spanish, or Portuguese, or Polish, or Russian text can be adopted as optional, for the touch screen operation language, for various customers in different countries or areas.
12. Some special requirements can be manufactured for you.

II. Specificatioin parameter

ModelNCF-200MNCF-300MNCF-400M
Metal sheet width200mm300mm400mm
Metal sheet thickness0.2-1.6mm
Feeding length per stroke 0.1-9999.99mm
Feeding length accuracy±0.1mm
Feeding speed0-20m/min
Electrical power380V, 3 phase, 50HZ (or other)
Motor power0.85KW0.85KW1.3KW
Feeding roller diameter66.5mm
Feeding rollers2 pieces
Roller releasing methodMechanical rod (for high speed)
Servo motor and driveYASKAWA (or other)
PLCMITSUBISHI (Jor other)
Human machine interfaceWEINVIEW (or other)
